MIS100-V2
IRIS Scanner
Mantra MIS100V2 is a high quality USB IRIS Scanner for IRIS Authentication. It provides higher security and usability with high-level image matching and better iris image assessment qualities. MIS100V2 is ultra compact that can auto capture the iris image of an individual.
Lowest FAR and FRR
STQC Certified Product
Supports Windows, Linux and Android Operating Systems.
Mantra MIS100V2 IRIS Scanner is a powerful and robust iris scanner, utilized in multiple projects and known for its accuracy and precision.
Mantra MIS100V2 IRIS Scanner can be utilized widely for identity applications like Aadhaar Authentication, Banking Applications and Access Control Applications. MIS100V2 quality algorithm can efficiently identify poor IRIS images that can be adjusted smoothly based on inbuilt LED indications. Our iris sensor is comprised of high Resolution CMOS Sensor that creates quality ISO/IEC 19794-6 Images with JPEG2000 compression. MIS100V2 proprietary distance sensing and focus analysis technology gives fast auto capture capabilities.
Plug & Play USB 2.0 with High Speed Interface
Lower FAR and FRR
STQC Certified Product
Supports Windows Operating Systems
Supports Android Operating Systems
Supports Linux Operating Systems
PC/Network Security
Time and Attendance
Smart Card Application
AFIS
Health & Medical
UIDAI
Jeevan Pramaan
AEBAS
Skill Development
NREGA
PDS
| Spatial Resolution | > 50% @ 1.0 LP/mm |
|---|---|
| Pixel Resolution | > 10 pixels/mm |
| Image Margins Left & Right | >=0.6x IRIS radius |
| Top & Bottom | >=0.2x IRIS radius |
| Imaging Wavelength | 700-900 nm |
| Pixel Depth | 8 bits/pixel |
| Output Image | KIND1 to KIND7 with JPEG2000 Compression |
| Capture Mode | Auto Capture with Built-in Quality Check |
| Capture Time | < 2 sec |
| Safety | Exempt Group per IEC 62471:2006-07 |
| Health-Safety | RoHS Compliant |
| ESD | Air Discharge+-8 KV, Contact Type +-4Kv |
| Radiated Emission | FCC part15B/IEC:CISPR 22 Class B Standard |
| Radiated Immunity | As per IEC/EN 61000-4 3:2006+A2:2010 |
| Connectivity | USB 2.0 |
| Operating System Supports | Windows XP, Win7, Win2008, Android, Linux, Embedded Linux |
Get the latest downloads includes software and drivers.
Download Drivers
