MR-110 is a fingerprint Time Attendance & Access Control Terminal, which can connect with Electric lock, Exit button. With SSR report(self-service Report) stored in the time clock. The 2.8inch TFT screen can display more information vividly, including fingerprint image and verification result etc. TCP/IP communication is a standard function which makes sure the data transmission between terminal and PC can be easily done within several seconds. Internal backup battery insures the device working normally when the power cut off suddenly. It's an ideal product for SMB market.

Technicle Specification
Display 2.8 inch TFT Screen
Fingerprint Capacity 2,000
ID Card Capacity 2,000 Proximity card
Record Capacity 2,00,000
Communication TCP/IP, USB-host
Battery Inbuilt Battery Back-up
Standard Functions Workcode, SMS, DLST, Self-Service Query, T9input, SSR report(optional), Automatic Status Switch , 9 digit User ID
Access Control Interface Electric Lock, Exit Button
Software PayTime / Minop
Power Supply DC 12V 1.5A
Operating Temp. 0°C ~ 45°C
Operating Humidity 20% ~ 80%
Dimension 185×140×30 mm
Certication CE, FCC, RoHS
