| Models | |
|---|---|
| 5 Mp/2.8 mm |
|
| Videostream | |
|---|---|
| Video protocol | JetSparrow
Fast and encrypted peer-to-peer video protocol developed by Ajax Systems. |
| Storage | NVR
Hard drive with a capacity of up to 16 TB (SATA connectivity, 3.5” size). Memory storage device not included. microSDUp to 256 GB. The memory card should be Class V30 or faster. Memory storage device not included. |
| Video codecs | H.265 H.264 |
| Dynamic range | True WDR |
| Communication channel | |
|---|---|
| Ethernet | up to 100 Mbps |
| Key features | |
|---|---|
| Motion detection | The camera has software to detect motion in the frame. |
| Object detection | using AI
|
| Smart IR illumination | up to 15 m
Automatic adjustment of intensity in real time to avoid overexposure. This allows you to see objects that are far away or too close to the camera in low light conditions. |
| Visual verification of Ajax alarms | The system allows you to set up a scenario when Ajax detectors activate selected cameras to start recording. The result is immediately sent to the mobile or desktop monitoring app. Learn More |
| Support for ONVIF authorization | Profile S Profile T (partially) Ajax cameras and NVRs can be integrated into third-party video management systems (VMS). Learn More |
| Microphone | With the corresponding settings, the camera records sound at the object. |
| Audio codec |
G711-ULAW G711-ALAW G726 G722 |
| Power supply | |
|---|---|
| Power supply unit | 12 V⎓ ± 20%, 1 А
Up to 15 W of mains power consumption. |
| Ethernet port | PoE Standard 802.3at/af |
| Sabotage protection | |
|---|---|
| mTLS | Encrypted connection for data protection. |
| Authentication | via Cloud
Without local access rights. |
| Secure Boot | Protection against firmware spoofing. |
| OTA signature verification | Secure automatic firmware update. |
| Privacy | Access rights distribution for users in mobile apps and for monitoring operators in PRO Desktop. Learn More |
| Enclosure | |
|---|---|
| Dimensions | 113 × 60 mm |
| Weight | 360 g |
| Operating temperature range | from −30 °C to +60 °C |
| Operating humidity | up to 90% |
| Protection class | IP65 |
| Complete set | |
|---|---|
| Complete set |
DomeCam Mini (5 Mp/2.8 mm) Installation template Installation kit Quick start guide |
| Additional information | |
|---|---|
| Compliance with standards | Learn more |
| User manual | Learn more |
| Warranty | 24 months Learn more |
