Home Automation
Wireless siren with an LED connector
Principle of operation
The device notifies of detector activation with an audible alarm. Sound level and alarm length are set in the mobile application.
Features
Connector for external LED is available. It can be mounted outside your apartment or office to monitor the security system status.
Installation and set up
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the siren. With one click, it can be connected to the hub in the mobile application. It can be mounted on the smart bracket in just a few minutes.
| Communication | |
|---|---|
| Jeweller communication technology |
Proprietary wireless communication technology to transmit commands, alarms, and events. Key features:
|
| Frequency band | 865.0–867.0 MHz |
| Maximum effective radiated power (ERP) |
up to 25 mW
Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation | GFSK |
| Radio communication range |
up to 2,000 m
Between the device and a hub (or a range extender) in an open space. Calculate radio communication range at the facility |
| Encrypted communication | All stored and transmitted data are protected by block encryption featuring a dynamic key. |
| Frequency hopping |
To prevent radio interference and jamming. Learn more |
| Key features | |
|---|---|
| Alarm type | Acoustic and LED indication (buzzer and LED) |
| Warning device type | Type W (internal, self-powered) |
| Alarm volume |
from 80 to 100 dB at a distance of 1 m (adjustable) 93 dB at a distance of 1 m (default) |
| Alarm duration |
from 3 s to 3 min Up to 15 minutes is available for sirens with firmware version NA 5.60.4.14 or higher. |
| Siren sound frequency | 3.4 ± 0.5 kHz |
| Additional LED connection |
3 V⎓ An additional LED works in parallel with the built-in LED and fully replicates its indication. |
| Events indication |
The siren makes a special sound to notify that opening detectors are triggered when the system is disarmed. Learn more |
| Recommendations | |
|---|---|
| Installation |
The siren is designed for indoor use only. Recommended installation height is 2.5 m or higher. |
| Sabotage protection | |
|---|---|
| Tamper alarm |
Notifications on attempts to detach the device from the surface or remove it from the mounting panel. Learn more |
| Protection against spoofing | Device authentication |
| Communication loss detection |
after 36 s Detection time depends on the Jeweller or Jeweller/Fibra settings. Learn more |
| Power supply | |
|---|---|
| Battery | 2 × CR123A (pre-installed) |
| Calculated battery life |
up to 5 years Learn more |
| Operating voltage range | 1.9–3.3 V⎓ |
| Nominal voltage | 3 V⎓ |
| Quiescent current | 68 µA |
| Peak current |
1.1 A When the siren sounds at the Very Loud volume level. |
| Average current |
50 mA At default volume level. |
| Battery capacity | 3,200 mAh |
| Low battery voltage | 2.1 V⎓ |
| End-of-life voltage | 1.9 V⎓ (device is switched off) |
| End-of-life capacity | 366 mAh |
| Manufacturer | Huiderui |
| Enclosure | |
|---|---|
| Dimensions | 75 × 76 × 27 mm |
| Weight | 97 g |
| Operating temperature | from −10 °C to +40 °C |
| Operating humidity | up to 75% |
| Protection class | IP50 |
| Colors | Black, White |
| Complete set | |
|---|---|
| Package contents |
HomeSiren Jeweller SmartBracket mounting panel 2 × CR123A battery (pre-installed) Connector for an LED indicator Installation kit Quick start guide |
| Additional information | |
|---|---|
| Compliance with standards | Learn more |
| User manual | Learn more |
| Warranty | 24 months Learn more |
