Port

Alarm Input

Supports local 16-channel alarm input,1 to 6 channels support pulse detection,and 1 to 16 channels support 0EOL/EOL/2EOL/3EOL
connected to a maximum of 500 m (1640.42 ft),(cable typed Rvv2*2.6，No strong electricity signal interference)

Alarm Output

Supports 4 local channels(Max 30 VDC, 3A)

Network Mode

Ethernet

Network Port

1 × RJ-45 10/100 Mbps Ethernet port;
PoE power supply

Storage Battery

Yes (12 V, 7 Ah.The backup battery is not included in the set）

Auxiliary Power Output

2 built-in auxiliary output, 14.5V, total 1 A (PoE), 2 A (Non PoE)

Function

Indicator Light

One indicator (indicator status)

Button

1 × switch button, 1 × reset button

Remote Update

Supports cloud update

Low Battery Detection

Yes

Tamper

Yes

Technical

Scenario

Indoors

Wireless

Carrier Frequency

433 MHz

Transmitter Power (EIRP)

limit 10 mW

Communication Mechanism

Two-way

Communication Distance

RF: Up to 1,200 m (3937.0 ft) in an open space

Encryption Mode

AES128

Frequency Hopping

Yes

General

Power Supply

100–240 VAC, 50/60 Hz. PoE (802.3at)

Power Supply Type

Type A

Standby Time

Static standby: Up to 30 hrs

Power Consumption

220 VAC quiescent current (40 mA Irms)
220 VAC max current@2Aload + charge (315 mA Irms)
POE quiescent current (125mA)
POE max current@0.75Aload + charge (612 mA)

Operating Temperature

–10 °C to +50 °C (+14 °F to +122 °F)

Operating Humidity

10%–90%

Product Dimensions

304 mm × 235 mm × 90.8 mm (11.97" × 9.25" × 3.57")

Net Weight

1.22 kg (2.69 lb)

Gross Weight

1.78 kg (3.92 lb)

Installation

Wall mount

Casing Material

PC + ABS

Appearance Color

White

Protection

IP30

Certifications

CE

Anti-corrosion Level

Basic Protection
*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Storage Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Humidity

10%–90%

Packaging Dimensions

369 mm × 140 mm × 280 mm (14.53" × 5.51" × 11.02") (L × W × H)
