Indoor use
Backlight keys
Built-in buzzer
Can connect external reader
Easy to install and program
Full programming from the keypad
Very low power consumption (30mA)
Can be used as a standalone keypad
Lock output current short circuit protection
Wiegand 26 output for connecting to a controller
2000 uses, supports Card, PIN, Card + PIN
Fast operating speed, < 20ms with 2000 users
Wiegand 26 input for connecting with a reader
Adjustable Door Output time, Alarm time, Door Open time
Built-in light dependent resistor (LDR) for anti tamper
Body
| Battery | NA |
|---|---|
| Body | Plastic |
| Dimension | 92*81*20 mm |
Functionality
| ID Card Capacity | 2000 |
|---|---|
| Record Capacity | NA |
| Card Type | Proximity card |
| Identify mode | Card, Password |
| LED Indicator | 2 LED Status (Green, Red) |
| Keypad Type | Numeric |
| Wiegand/RS485 Interface | Wiegand Input & Output 26/34 bit |
Technicle Specification
| Communication | NA |
|---|---|
| Operation Humidity | 10% ~ 80% |
| Operation Temperature | 10° C ~ 60° C |
| Power | DC 12V 3A |
Accessories
| Wiring Connections | External Card Reader, Electric Lock, Exit Button |
|---|
