MFSTAB-3G
Fingerprint Biometric machine
MFSTab 3G fingerprint biometric machine offers the perfect platform for mobility, versatility and data security, enabling you to deliver trusted services in any sector, anytime, anywhere.
STQC, UIDAI, CE, IEC Certified Fingerprint Sensor
ISO Compatible Fingerprint Templates and Images
3.5mm Ear Jack, Microphone, Inbuilt Speakers
Mantra MFSTAB fingerprint biometric machine is meant for replacing conventional security and surveillance practices in business. There are various applications of the device such as Time and Attendance management system, Access Control system, Work flow Management, Canteen Management, Visitor Management, Worker Management etc.
The ability to monitor the workforce activities can be improved with the help of this innovative Biometric device that offers advanced features to take time and management system on next level.
The MFSTAB 3G fingerprint biometric machine is suitable for both basic to slightly complicated time and attendance system requirements. A wide range of possibilities is offered by the biometric device starting from the classical Time recording to a complicated Factory Data Collection. It gives a high security solution with access queries supported with fingerprint recognition.
STQC, UIDAI, CE, IEC Certified Fingerprint Sensor
ISO Compatible Fingerprint Templates and Images
GPS/AGPS Location Technology
3.5mm Ear Jack, Microphone, Inbuilt Speakers
Capacitive 7" Touch screen of 1024x600 pixels
Front VGA Camera, Rear - 5MP Camera
8GB Memory with 1 GB RAM
WIFI, Bluetooth Enabled
2G & 3G Enabled
1.2GHz Quad Core Processor
Dual SIM Card Support
Android 5 OS
4500 mAh Battery
Time Attendance
Visitor Management
Aadhaar Authentication
Access Control
Canteen Management
Financial Inclusion/eKYC
Worker Management
| Display | 7 inch TFT LCD |
|---|---|
| Processor | 1.3 GHz Quad Core, 32bit |
| RAM | 1GB RAM |
| Memory | 8GB with Expandable up to 32GB |
| OS | Android 8.1 GMS |
| Display Resolution | 1024 x 600 Pixels |
| Audio Jack | Yes |
| Ports | Micro USB v2.0 Port - 1nos. (with OTG Support) or One Micro USB v2.0 Port & One Round Pin Charger Connector |
| Wifi | 802.11 b/g/n 2.4GHz |
| Bluetooth | Bluetooth Classic |
| SIM Slot | Supports 3G Bands & Dual SIM Card |
| GPS | GPS/AGPS |
| Camera | 5 MP FF Front, 5 MP AF Back |
| Baseband Version | MOLY.WR8.W1449.MD.WG.MP.V173.2,2018/04/24 |
| Battery | 3500 mAh |
| Certification | ISO Compatible Fingerprint Templates and Images ANSI Compatible Fingerprint Templates and Images 500 DPI STQC/Aadhaar Approved Fingerprint Sensor CE, IEC60950,RoHS Certified Fingerprint Sensor |
| Connectivity | GPRS/EDGE Enabled, 2G, 3G, 4G, GPS |
| Acceptance and Rejection Rate | Lower FRR and FAR |
| Fingerprint Sensor | Optical (Scratch Free Sensor Surface) |
|---|---|
| Image Resolution | 500 DPI / 256 Gray |
| Sensing Area | 16 x 18 mm |
| FAP | FAP10 |
