It can be used in Electronic Toll Collection & transport systems, vehicle identification. Factory automation, Automotive & Security purpose.
Chip Type:
| EPC Class 1 Gen 2; ISO 18000-6C protocol compliant |
| Alien Higgs 3 having EPC 96 bit extendable up to 480 bit |
| User Memory 512 bit |
| Data retention of 50 years |
| Write endurance of 100,000 cycles |
Mechanical:
| Dimension | 95 x 35 x 0.3 mm |
|---|---|
| Material | PP label |
| Color | White |
| Weight | 0.11 g |
Electrical:
| Operating Frequency | 865 – 868 MHZ |
|---|---|
| Operating mode | Passive (battery-less transponder) |
Ingress Protection:
| Ip65 |
Thermal:
| Storage Temp. | -40°C to +100°C |
|---|---|
| Operating Temp. | -20°C to +80°C |
Options:
| Available with | Other IC type on request | Tags are delivered in rolls. |
|---|
