Tracking of garments in the textile rental and dry Cleaning. The Laundry Tag provides immediate and long term benefits to garment management in process and lifecycle traceability. Automatically reading of garments and provide a durable tag that could survive multiple washings
Chip Type:
| I-Code SLIX 13.56 MHz, ISO/IEC 15693 |
| 1024 bits, organized in 32 blocks of 4 bytes each |
| Data retention of 50 years |
| Write endurance 100,000 cycles |
Mechanical:
| Outer Dia. | 15.8mm |
|---|---|
| Thickness | 2.85mm |
| Hole Dia. | 1.5mm x 2 |
| Material | High Temp Plastic |
| Colour | Black |
| Weight | 0.9 g |
| Stability | Isostatic water pressure 30 bar |
| Antenna Type | Wire Antenna |
Electrical:
| Operating Frequency | 13.56 MHz |
|---|---|
| Operating mode | Passive (battery-less transponder) |
Ingress Protection:
| Ip68 |
Thermal:
| Storage Temp. | -40°C to +120°C, (+160°C for 50 min., +220°C for 50 sec.) |
|---|---|
| Operating Temp. | -25°C to +85°C |
Options:
| Available with | Other IC type, Size, Shape & Colour on request |
|---|
