Manufacturing Automotive Trolley/ Pallet Tracking PIPE & Spool Tracking Construction Material Tracking
Physical:
| Size (L X W X H) in MM | 150 x 25 x 12 (Hole Dia: 5.8, 8) |
|---|---|
| Size (L X W X H) in Inch | 5.90 x 0.9 x 0.4 (Hole Dia: .21, .31) |
| Operating Temperature | -40˚C to +80˚C |
| Storage Temperature | -40˚C to +80˚C |
| IP Rating | IP 67 |
| Weight | 17.00 g |
| Material | ABS |
| Color | Grey |
| Attachment | With Foam Adhesive Revit or Magnet |
Electrical:
| Protocol Operating Mode | EPC Class 1 Gen 2 |
|---|---|
| Operating Mode | UHF Passive |
| Operating Frequency | ETSI: 865-868MHz FCC: 902-928MHz (Available on Request) |
| IC Type | Alien Higgs - 3 |
| Memory | TID : 96 bits EPC : 96bits User : 512 bits |
| Data retention Write endurance | 50 years |
| Write endurance | 100,000 cycles |
| • Up to 13 M on Fixed Reader | |
| • Up to 6 M on Handheld Reader | |
| Read Range* | OFF Metal: |
| • Up to 13 M on Fixed Reader | |
| • Up to 6 M on Handheld Reader |
Customization Options:
| Encoding | Serialized or Variable |
|---|---|
| Printing | Barcode, QR Code, Logo Etc. |
| Laser Engraving | Barcode, QR Code, Logo Etc. |
| Adhesive | Foam Adhesive |
| IC | Various Options Available, Depending upon requirement |
| Versions | 1. Mount on Metal 2. Free Air |
