Tags Specification:
Tag Dimension (mm) | 120 x 19 x 0.85 mm |
---|---|
Surface Material | PVC |
Frequency | 865 – 868MHz |
IC Type | Impinj Monza R6P |
Protocol | EPC Class 1 Gen 2 ISO 18000-6C |
Memory of IC | TID : 96 Bits EPC : 128 Bits USER : 32 Bits |
Read/Write Endurance | 100,000 Cycles |
Data Retention | 50 Years |
Encasement | ABS |
Size(mm) | 62 x 36.50 x 12 |
Hole Dia | 3.0 |
Weight(g) | 15.80 |
Operating Temperature | -40°C to +80°C |
Storage Temperature | -40°C to +80°C |
Ingress Protection | Ip67 |
Attachment | 2xØ3mm Holes, Rivet/Screw, Foam Adhedive Tap |
Certifications | RoHS, REACH & CE (optional) |
Typical Application | Metallic as well as Non-Metallic Asset tracking, |
Automotive Supply chain, Plastic container | |
Customization Options | Laser Engraving, Encoding, Adhesive |
